Linking rules

A linking rule is a schema object that declares when mushroomdb should create an edge between two nodes. Once declared, the rule fires automatically on every insert_node and set_prop call — incrementally, not in batch.

Derived edges carry rule provenance (visible via explain and the UI why panel) and are retracted automatically when the properties that matched them change.

Reproduce the GIF above with vhs scripts/rule-fire-explain.tape — it shows the FIT edges before and after a SET that retracts one and fires another, then calls explain on the edge that survives.

Declaring a rule

Rules are declared with GraphDb::create_rule (Rust), the POST /rules endpoint (HTTP), the MCP create_rule tool, or db.create_rule() (Python bindings). The schema is RuleDef:

#![allow(unused)]
fn main() {
pub struct RuleDef {
    pub name: String,          // unique rule identifier
    pub src_label: String,     // source node label
    pub dst_label: String,     // destination node label
    pub predicate: Predicate,  // one of the six kinds below
    pub edge_type: String,     // edge type written to the graph
    pub weight_prop: Option<String>, // if Some, score stored as this edge prop
    pub max_edges: Option<usize>,    // best k per source node (per-source top-k)
    pub approximate: bool,     // HNSW approximate mode (VectorSimilar only)
    pub namespace: Option<String>,   // None = global; Some(ns) = scoped (see below)
    pub via_label: Option<String>,   // intermediate-hop label (via-hop rules)
    pub via_edge: Option<String>,    // edge type to traverse for the via hop
    pub via_dir: Option<Direction>,  // direction of the via hop (default Out)
}
}

All label, edge-type, and field names are arbitrary user strings. The engine has no reserved names.

Six predicate kinds

1. KeyMatch

Matches when a field on the source node equals the destination node’s key. This is the FK-style predicate, and it also runs automatically on *_id fields via auto-FK inference at ingest time.

#![allow(unused)]
fn main() {
Predicate::KeyMatch { field: "org_id".into() }
}

Demo example: auto_fk_person_org_id — every Person whose org_id field matches an Org’s key gets a ORG edge to that Org. After the demo, 30 such edges exist (one per Person).

Score: 1.0 when the field matches the destination key.

List-valued fields (multi-valued FK): when the field holds a list instead of a string, it is read as a set of foreign keys. Every string element that names a live destination node gets its own edge, so File.imports = ["a.rs", "b.rs"] yields two IMPORTS edges. Elements that name nothing are ignored until that node appears, at which point the edge is filled in; drop an element and only that edge is retracted, in the same write. Non-string elements are skipped and duplicates collapse into a single edge. At most MAX_KEYMATCH_LIST = 512 elements are considered, in stored order, so one node can never fan out without bound — the same list always produces the same edges.

Firing per element is the default, not an opt-in: a KeyMatch rule that omits max_edges gets 512, the same number, from every front door that fills the cap — POST /rules, MCP create_rule, the Python binding, suggest, and the auto-FK rules declared at ingest time. A scalar FK field names at most one destination, so the higher cap is inert there and scalar rules behave exactly as they did. Rules stored before this change keep the max_edges they were written with, so a rule saved with max_edges: 1 still keeps a single destination per source until it is recreated.

2. FieldEqual

Matches when a named field on the source node exactly equals the same field on the destination node. Comparison is on any scalar ValueKey (string, int, float, bool), not strings only. An empty string is a value like any other: two nodes whose field is "" match, at score 1.0. Leave the field unset, or remove it, on a node that should not be linked.

#![allow(unused)]
fn main() {
Predicate::FieldEqual { field: "industry".into() }
}

Score: 1.0 when the fields match; the edge is not written when they differ.

Scores are stored on the edge under weight_prop (MCP default weight); explain reports the score even for rules that store none. Via-hop rules are the exception: they score over the via set, so explain reports their stored score only.

For a rule declared with no weight_prop at all (only reachable via the Rust API — the MCP create_rule tool always defaults it to "weight"), explain still reports the recomputed score (1.0 for KeyMatch/FieldEqual), but the EdgeFired subscription event’s weight field (Option<f64>) is absent (omitted) from the JSON payload — because it only looks up the stored prop, not the predicate.

Example: two Talent nodes both with industry = "architecture" get a INDUSTRY_ALIGNMENT edge between them (score 1.0).

3. Overlap

Computes the Jaccard coefficient between the same list-valued field on both nodes — field names one property, read on the source and on the destination — and writes an edge when the coefficient meets a minimum threshold.

#![allow(unused)]
fn main() {
Predicate::Overlap { field: "skills".into(), min: 0.5 }
}

Score: Jaccard value, stored on the edge via weight_prop.

Demo example: skill_fit — Person.skills vs Project.skills, min 0.5. After the demo:

  p=person-01  proj=proj-01  score=1.0   (full overlap)
  p=person-01  proj=proj-02  score=0.5   (partial)
  p=person-01  proj=proj-20  score=0.5   (partial)

90 FIT edges total across 30 People and 20 Projects.

4. NumericWithin

Matches when the absolute difference between a numeric field on the source and the same field on the destination is within a tolerance. Score is 1 - |Δ| / tolerance, so exact matches score 1.0 and the boundary scores 0.0.

#![allow(unused)]
fn main() {
Predicate::NumericWithin { field: "founded_year".into(), tolerance: 2.0 }
}

Demo example: founded_within — Org.founded_year, tolerance 2. An Org founded in 2010 and one in 2011 score 1 - 1/2 = 0.5. 34 FOUNDED_WITHIN edges in the demo dataset.

5. GeoRadius

Matches when the Haversine distance between two [lat, lon] fields is within a radius (in km). Score is 1 - distance / radius.

#![allow(unused)]
fn main() {
Predicate::GeoRadius { field: "office".into(), km: 50.0 }
}

Demo example: nearby_office — Org.office, 50 km. Uses real city coordinates. 16 NEARBY edges in the demo dataset.

Field format: the field must contain a two-element numeric list [latitude, longitude] in decimal degrees.

6. VectorSimilar

Computes cosine similarity between two fixed-dimension float array fields and writes an edge when similarity meets a minimum threshold.

#![allow(unused)]
fn main() {
Predicate::VectorSimilar { field: "embedding".into(), min: 0.8 }
}

Score: cosine similarity, stored on the edge via weight_prop.

Demo example: similar_interests — Person.embedding, dim 8, min 0.8. 114 edges in the demo dataset.

Candidates come from the vector index — 0.6.6, behaviour change. A VectorSimilar rule with approximate: false used to compare every pair of vectors on the two sides: O(n²), measured at 147 s to create the rule over 5,000 nodes at dim 1536 (exact_vector_rule_recall_5k with MUSHROOMDB_VECTOR_SCAN=1). From 0.6.6 it asks the same in-tree HNSW index the approximate mode uses for its candidates, and the rule’s own min is the beam’s stopping rule: the beam widens, doubling from ef_search (400 by default) up to a ceiling of 4,096, until it has something to conclude.

The index is a candidate generator here and never a silent filter. There is exactly one outcome that lets it narrow the candidate set: a beam that comes back full — as many hits as it had room for — whose worst hit is below min. That beam has proved what it left out, because everything it rejected is farther from the query than a node already known to fail the predicate. Every other outcome falls back to every vector on that side of the rule, the same candidate set the rule used before 0.6.6:

• a beam that comes back short of its own width, which is what an HNSW layer 0 that is not one connected component looks like — a corpus of identical or near-identical embeddings is the case that produces it;
• the 4,096 ceiling reached with the worst hit still at or above min, so a cluster denser than the ceiling costs a scan and never costs recall (the comparison carries a small tolerance, because a graph search answers in f32; the rounding can only buy an extra doubling, never drop a pair);
• a beam that would be as wide as the index itself, which is every rule over fewer vectors than the default width — small rules stay exhaustive and never walk the graph at all;
• an index that cannot answer the query at all: no graph yet, a dimension that is not the query’s, or one that skipped a vector it was handed (see one fixed dimension per index). Checked before any beam runs, because a beam over an index missing part of the corpus would “prove” its floor against vectors the index never held.

All([VectorSimilar, …]) conjunct rules take the same path. The vector conjunct contributes the beam’s candidates (or the whole side, per the rules above) and the other conjuncts contribute their own index lookups; the rule’s candidate set is the intersection, and evaluate then decides every pair as it always has.

Scores did not move. Every candidate the beam offers is re-scored exactly, from the stored f64 vectors, by the same code that scored the full scan — so the similarity on the edge, the weight_prop value and the max_edges ranking are bit-for-bit what they were. What changed is the candidate set: the derived edge set is no longer provably every pair above min, it is every pair above min that the beam found. The committed floor for that is recall ≥ 0.98 against an O(n²) ground truth, asserted by exact_vector_rule_recall_5k (5,000 nodes, dim 1536, in crates/sim-harness/tests/oracle_equivalence.rs), which measures 1.0000 — 495,000 of 495,000 pairs — on that fixture. On a corpus small enough for the beam to reach every vector the two paths agree edge-for-edge (index_backed_vector_rule_equals_brute_force_on_a_fixed_set).

Buying the guarantee back: set MUSHROOMDB_VECTOR_SCAN=1 and every exact VectorSimilar rule returns to the full scan — O(n²), every pair above min provably found, and the backfill time that goes with it. Rules with approximate: true are unaffected by the variable.

Composing predicates — All and Any

All — require every branch

Require multiple conditions on the same edge by wrapping predicates in All:

#![allow(unused)]
fn main() {
Predicate::All(vec![
    Predicate::FieldEqual { field: "region".into() },
    Predicate::Overlap { field: "tags".into(), min: 0.3 },
])
}

The edge is written only when every sub-predicate fires. The score is the minimum of the individual sub-predicate scores (score.min(part_score) per part — verified in crates/core-rules/src/def.rs, test all_takes_min_score_and_requires_every_part).

Any — require at least one branch

Match when at least one branch fires by wrapping predicates in Any:

#![allow(unused)]
fn main() {
Predicate::Any(vec![
    Predicate::Overlap { field: "tags".into(), min: 0.3 },
    Predicate::NumericWithin { field: "founded_year".into(), tolerance: 2.0 },
])
}

The edge is written when any sub-predicate fires. The score is the maximum of the satisfied branches’ scores (score.max(branch_score) — verified in crates/core-rules/src/def.rs, test any_score_is_max_when_both_branches_match).

Nesting

All and Any nest freely:

#![allow(unused)]
fn main() {
Predicate::All(vec![
    Predicate::FieldEqual { field: "region".into() },
    Predicate::Any(vec![
        Predicate::Overlap { field: "skills".into(), min: 0.3 },
        Predicate::NumericWithin { field: "founded_year".into(), tolerance: 2.0 },
    ]),
])
}

The combined score follows the two conventions above: All takes the minimum over its branches’ scores; Any takes the maximum. In the example above the combined score is min(1.0, max(overlap_score, numeric_score)).

Depth cap: nesting depth is capped at 4. validate() returns a named error ("predicate nesting depth N exceeds cap of 4") when the limit is exceeded.

Approximate mode (VectorSimilar only)

Setting approximate: true on a VectorSimilar rule switches the candidate path from a full scan to in-tree HNSW (Hierarchical Navigable Small World):

#![allow(unused)]
fn main() {
RuleDef {
    predicate: Predicate::VectorSimilar { field: "embedding".into(), min: 0.85 },
    approximate: true,
    max_edges: Some(1000),
    ..
}
}

How it works: at rule creation time, an HNSW graph is built over the destination-side vectors (cosine similarity, in-tree implementation — no external ANN dependency). Each node insertion incrementally updates the HNSW graph. On each lookup, the HNSW index returns the approximate k nearest neighbors. IVF-Flat centroids are also maintained as a fallback; the primary candidate path is HNSW. The HNSW graph is persisted in the snapshot alongside IVF centroids so WAL replay and snapshot open avoid full re-fitting. Opening a store whose snapshot holds that graph loads it directly and never rebuilds it; the rebuild is the fallback for a rule with no persisted graph, or one whose persisted graph fails to load (the reason is logged).

Trade-offs:

Creation time, measured (release, 5,000 nodes × 1,536-D, fixed-seed probe, both printed by exact_vector_rule_recall_5k):

The index path replaces a quadratic derivation with a beam and pays a one-time graph build for it. That build is the term that moves: measured mid-release, at the halved parameters but still on the f64 distance, creation came out at 287 s — slower than the scan it removed. (That is a within-release figure, not a 0.6.5 one: 0.6.5 had no index-backed exact rule to time.) The halved index parameters and the f32 slab kernel cut it to the figure above. Quote the test, not this table, after any further change to either: the gap is a property of the graph’s shape, and the scan term grows as n² while the build grows as roughly n·log n·ef·dim, so the margin widens with the corpus.

Use approximate mode when a lower recall floor and a bounded k per source are acceptable. When completeness is required (safety-critical graph closure, compliance checks) neither mode is enough on its own — set MUSHROOMDB_VECTOR_SCAN=1, which is the only path that proves it.

What an exact rule now costs in memory and on disk. It builds and keeps the same two graphs an approximate rule does — one per side — at the same per-vector cost (6,663 B per node at 5,000 × 1,536-D and the defaults), so a rule whose src and dst labels are the same indexes the corpus twice: about 33 MB per side at that size. Both graphs are written into the snapshot so that reopening adopts them instead of rebuilding, which is the same trade the approximate mode has always made, and MUSHROOMDB_VECTOR_SCAN=1 does not release it: a session under the variable still loads and re-persists the graph, so unsetting it later costs nothing. A rule created while the variable is set builds no graph at all, and the first open without the variable builds one from the node scan (logged, with the vector count).

The explain endpoint marks approximate edges with "approximate": true in the predicate summary.

Creating a rule over a large corpus

Building an HNSW graph is superlinear in the number of vectors, and create_rule holds the write lock for the whole of it. Above 2,048 vectors (core_rules::HNSW_BUILD_BATCH) the build is therefore sliced: create_rule installs the rule, files every non-vector index leg, indexes the first 2,048 vectors, and returns before its edges exist.

This applies to both kinds of VectorSimilar rule from 0.6.6 on, because both build a graph — an approximate: false rule over more than 2,048 vectors is sliced exactly as an approximate one is. (A rule whose vector predicate sits under an Any, and any rule created while MUSHROOMDB_VECTOR_SCAN=1 is set, builds no graph and is never deferred.)

create_rule ──▶ rule installed, 2048/120000 indexed, 0 edges
   pump ──▶ 4096/120000 ─▶ … ─▶ 120000/120000 ─▶ backfill (one commit) ─▶ edges

While a rule is in that state:

• GET /stats (and GraphDb::stats) reports it under building ({"rule", "indexed", "total"}), and POST /rules answered 202 Accepted.
• It derives no edges. Never a partial set: the backfill is a single commit that runs after the index is whole, through the same path rebuild_rule uses.
• No search answers from it while it is partial. find_similar, hybrid_search and a rule’s own candidate lookup all decline a rule with a build outstanding and take the exhaustive path instead, so a query mid-build is slower and never answers about the fraction of the corpus the index has reached. A snapshot taken mid-build records the fact in its index blob, so a reader that opens it declines for the same reason with no live state to consult.
• Three things advance it, and any one of them is enough:
  1. Any write. Every durable commit does one slice on its way out, so a store that is being written to finishes on its own. That slice is paid for by the writer, under the write lock: 2,048 inserts, which at 1,536 dimensions is roughly 9–27 seconds. A latency-sensitive writer should let build-index finish the build first.
  2. mushroomdb serve. A 1-second ticker calls pump_index_build, so a quiescent server finishes a build its own handle has registered. Open registers a build a snapshot cut short, so a restarted serve advances it without waiting for a write.
  3. mushroomdb build-index <db-dir> [--rule <name>]. Drives it to completion now, one progress line per slice, for an operator who wants the build done before traffic arrives. --rule narrows the report, not the work — pending builds share one write lock. GraphDb::pump_index_build is the Rust equivalent: one write lock and at most one slice per pending rule per call, and Err(ReadOnly) on a read-only handle (it could advance the index but not commit the backfill).

A store killed mid-build reopens with the rule present, its index partly built, and that build already registered: stats().building is populated from the blob’s complete == false flag, so serve’s ticker and pump_index_build have something to advance without a write. The snapshot’s graph covers what it carried; the remainder is sliced the same way create_rule sliced it — one batch per pump, under the write lock, never the whole rest of the corpus in one pass. A handful of vectors written after a complete snapshot still land inline on open: that is the fast path 0.6.5 fixed and it stays. A snapshot taken after that reopen but before the next pump still records the index as incomplete, so a reader opening that snapshot answers by brute force until a write, serve, or build-index pumps it — slower, never wrong. A live handle whose build is still outstanding takes the same door.

How that is told apart from an ordinary write: a store restored from a snapshot defers building its candidate indexes until the first write, and the write path runs that build before it applies the record. The scan therefore reads exactly the state the snapshot persisted, so a vector it has to supply really was missing from the persisted graph rather than being the in-flight write’s own; the record’s own hook files that write a moment later through the normal insert path. (Ids are dense and never reused, so the snapshot’s id count is kept as a second line of defence for any caller that still populates lazily — a what_if clone, say.)

what_if while a build is pending. what_if_set_prop answers from a clone of the engine, and the clone carries no pending-build state. During a real pending build it therefore reports the gained edges the rule would derive, which the live store will not derive until its backfill runs. The preview is right about the end state and early about the timing.

Vector index parameters

The HNSW graph has one shape, store-wide — not per rule. Nothing in it is persisted: the parameters bound how a graph is built, never how a built graph is read, so a snapshot written under one shape opens correctly under any other.

Since 0.6.6 the new node’s neighbours are chosen by a diversity test taken from the HNSW paper’s §3.5 heuristic (Algorithm 4): a candidate is kept only when it is closer to the node than to every neighbour already kept, because a candidate sitting behind an existing neighbour is already reachable through it. m0 was 128 before 0.6.6 purely to compensate for not having that test, and halves now that it exists.

It is a short-cut of Algorithm 4, not Algorithm 4. Once enough candidates have been rejected that the rest would fit anyway, mushroomdb takes the remainder untested rather than continuing to test and then backfilling with the nearest rejects (the paper’s keepPrunedConnections). The two build different graphs, and the short-cut measured better on both axes:

The reason the paper’s version loses here is keepPrunedConnections: it fills a shortfall with the nearest rejects, and in a cluster wider than m0 those all point back into the cluster the diversity test just turned down. Keeping the untested far candidates instead preserves the longer-range links that make a cluster reachable from outside it. Expect a different graph from a textbook implementation, and do not “fix” the deviation without re-running these three gates — select_neighbors_first_rejection in crates/core-rules/src/hnsw.rs carries the same table.

ef_search did not fall with the rest. At 1,536 dimensions the nearest-neighbour distribution is flat enough that recall is a beam-width problem before it is a graph-shape problem, and hnsw_5k_1536_recall rejects every narrower beam: at ef_search = 128 its min recall@10 is 0.30 at m0 = 32 and 0.70 at m0 = 64, against a floor of 0.90. The shape the 0.6.6 design sketch proposed — 16,32,200,128 — was rejected on that measurement: its min recall@10 is 0.30 against the gate’s floor of 0.90.

prune: how far the heuristic reaches

The heuristic always chooses the new node’s own neighbours. Whether it also re-decides each over-connected neighbour’s list is the prune field, and it is the parameter with the sharpest trade-off in the set.

Measured three ways, all at m,ef_construction,ef_search = 16,200,400:

Every build time in this section and the one above it was measured before the distance kernel, which cut the 5 000 × 1 536-D build from 45.8 s to 9.56 s at own (4.8×) and from 254 s to 43.34 s at both (5.9×) without changing a single edge. The comparisons between the rows stand; the absolute seconds are history.

own is 4.5× faster to build on a corpus of genuinely distinct vectors (9.56 s against 43.34 s for the raw 5 000 × 1 536-D index, with identical hnsw_5k_1536_recall at min 1.0000 / mean 1.0000), which is why it exists. But the corpus that matters has clusters wider than m0 — 100 members against an m0 of 64 — and there the neighbour side is exactly where the long-range links get discarded: own loses 14% of the derived edges and misses the floor.

Both ways of fixing that work, and both at m0 = 64 wins on every axis: it is faster end to end than raising m0, and it keeps the halved adjacency memory. So both is the default and own is the opt-out, for an operator who has measured their own corpus and knows its groups stay under m0:

MUSHROOMDB_HNSW_PARAMS=16,64,200,400,own mushroomdb serve ./db

clustered_recall_survives_clusters_wider_than_m0 measures both strategies side by side on a 40 × 120 fixture (own min 0.5000 / mean 0.9350, both min 0.8000 / mean 0.9950) and asserts that both stays ahead, so this gap cannot drift unnoticed.

Overriding them. Set MUSHROOMDB_HNSW_PARAMS to m,m0,ef_construction,ef_search with an optional fifth field for prune (both, the default, or own):

MUSHROOMDB_HNSW_PARAMS=16,64,300,256 mushroomdb serve ./db

It is read once per process, before the first insert. Unset, malformed, or carrying a zero in any numeric field, it falls back to the defaults above — a zero m0 is a graph with no edges. It is for benchmarking and for an operator who has measured their own corpus; there is no per-rule knob.

Memory per indexed vector, as arithmetic rather than as a measured total: m0 × 4 bytes of layer-0 adjacency plus dim × 4 bytes for the index’s own copy of the vector, so 256 B + 6,144 B at the defaults with a 1,536-D embedding. Layers above 0 add m × 4 bytes for the minority of nodes that have them, and the reverse-adjacency index that makes a removal O(in-degree) holds one more u32 per link — so the adjacency figure roughly doubles in practice. Halving m0 halves all of it. Measured at 5,000 × 1,536-D: 6,663.2 B per node (519.2 adjacency + 6,144 vector), against 12,807.2 before the index’s copy became f32 — a 48.0 % cut, and the persisted index blob halves with it.

The distance kernel

The index keeps its own copy of every vector as f32, in one contiguous slab addressed by slot, and the store keeps the f64 properties untouched. That is safe for one reason, and it is a rule every caller has to keep: the index supplies candidates, and the score comes from the f64 vectors.

An f32 dot of two 1,536-D unit vectors is accurate to about 2e-6 — far below the granularity at which candidate order matters, which is why the recall gates below are unchanged on the f32 path, and nowhere near good enough to report. An exact duplicate scores 0.9999999 there, so a threshold of min = 1.0 applied to the index’s own number would return nothing at all. So:

• Rule weights were always recomputed from the f64 properties (def.rs::cosine), and still are.

• find_similar_vector and find_similar_vector_masked treat the index’s hits as candidates only: they over-fetch (k + 16; under a mask, k × n / |visible| when selectivity is known, then a ×2 beam-widening loop capped at EF_MAX, falling back to an exhaustive masked scan rather than returning short of k), re-score every candidate against the f64 property vectors, and apply min, the ordering and the reported score to that number. Every score you receive is the one the brute-force scan would have produced, to f64 precision, and equal scores are ordered by node key rather than by which path found them.

  Which nodes come back can still differ from the scan in one case: a tie cluster wider than the 16-candidate margin. If more than sixteen vectors sit within about 1e-6 of each other across the k boundary, the index’s f32 order decides which of those interchangeable members is fetched, so the scan may return a different — equally-scoring — node. Ask for an exact top-k over a corpus of near-duplicates through a rule with approximate: false, which never touches the index.

A new caller must do the same; HnswIndex::search’s doc comment says so.

The dot product itself is summed in eight independent accumulators over chunks_exact(8). IEEE addition is not associative, so a single accumulator is a serial dependency chain as long as the vector: compiled for aarch64, the old f64 loop vectorised its multiplies (fmul.2d) and then added them one at a time (fadd d0, d0, …), 1,536 links of 3–4 cycle latency each. Choosing the summation order in the source is what lets the compiler emit four-lane work for both halves — ldp q, q / fmul.4s / fadd.4s, eight lanes per iteration. (std::simd would say this declaratively and is nightly-only; the toolchain is pinned stable, and -C target-cpu=native is not available to a published crate, so NEON on aarch64 and SSE2 on x86-64 — four-wide, no FMA — are what this buys. Expect a smaller win on x86-64 than the figures below, which are aarch64.)

What it cost in work per insert is nothing: the evaluation count at 1,000 and 5,000 nodes is identical before and after, because the slab changed no decision the graph makes, and the adjacency it builds is byte-for-byte the same size. What it bought, at 5,000 × 1,536-D:

One fixed dimension per index, and the index steps aside when it cannot answer for everything. A slab has one stride, so the dimension of the vectors an index holds is settled by the ones it is given, and an embedding of any other length is skipped — logged once per index, not indexed, not counted. Two consequences, and the second is the one that keeps results correct:

• A skipped vector is never an edge. It could not have been one anyway: a vector_similar predicate refuses a pair of unequal length, before and after 0.6.6. (Since 0.6.6 this holds for approximate: false too — an exact rule takes its candidates from the index as well, and the fallback in the next bullet is what keeps it exact.)
• An index that skipped anything, or whose dimension is not the query’s, stops claiming the fast path: the rule falls back to its full scan and find_similar_vector to its brute-force scan. Slower, and exactly right. So a mixed-dimension corpus costs speed, never edges.

The first vector indexed would otherwise set the dimension on a sample of one, so a single stray ahead of a real corpus would refuse the whole corpus. That case is corrected rather than endured: when an index holds exactly one vector and the next one disagrees, it re-elects its dimension to the newcomer’s and drops the stray.

Mixed dimensions were never meaningful; this is the version that says so. Re-embed a collection with one model rather than mixing two.

Blob version 4. The persisted graph carries the slab, so its version is 4. Earlier versions (v1–v3) still load, converting the vectors in memory with no vector re-inserted and no distance computed. A reader older than this one meeting a v4 blob fails its version check and leaves that rule on its full-scan fallback — slower, never wrong. The snapshot format does not move: it carries the index as opaque bytes.

The recall these defaults are held to, by tests that run in CI’s recall-gates job:

A parameter set that cannot pass those is not shipped.

Measuring a change to them. crates/core-rules/tests/hnsw_scale.rs builds 2k / 10k / 50k indexes at 1,536-D and asserts the build stays sub-quadratic, the 50k case finishes, and re-embedding one node costs the same at 50k as at 2k. It is a wall-clock measurement, so it is not in CI:

MUSHROOMDB_BENCH_HNSW=1 cargo test --release -p mushroomdb-rules \
  --test hnsw_scale -- --ignored --nocapture

Its sibling hnsw_memory_per_node_5k_1536 prints bytes per indexed vector, and honours MUSHROOMDB_HNSW_PARAMS, so a proposed shape can be compared against the default before it is adopted.

Measured at the defaults (prune = both, 1,536-D, one core), before and after the distance kernel:

Two of its assertions still do not pass, and the benchmark is committed failing on purpose. The build grows 15.48× from 2,000 to 10,000 vectors against a ceiling of 8×, and the 50,000 case takes 17 minutes against a ceiling of five. What the 50,000 row adds is the reason: from 10,000 to 50,000 the same step costs only 7.71×, which is inside the ceiling. The steep first step is a regime, not an asymptote — at 2,000 nodes a beam that may touch ef_construction × m0 = 12,800 distinct nodes cannot touch more than 2,000, so the small point is measured where an insert is effectively exhaustive, and the §3.5 prune’s candidate walk is still getting denser. Counted rather than timed: an insert evaluates 12,739 distances at 1,000 nodes and 23,901 at 5,000, a climb of 1.88× with no N in either formula, and dist_evals_per_insert_is_bounded gates exactly that count in CI.

Closing the rest means cutting the count — ef_construction, or a budget that truncates the prune’s walk — and both change the graph, so both are the recall table’s business. Until then, building a large vector index is something to do once, ahead of traffic (see Creating a rule over a large corpus above), not something to absorb inline.

Namespace scoping

A rule is either global or scoped to one namespace. The namespace field decides which:

#![allow(unused)]
fn main() {
db.create_rule(RuleDef {
    name: "tenant-a-similar".into(),
    src_label: "Document".into(),
    dst_label: "Document".into(),
    predicate: Predicate::VectorSimilar { field: "emb".into(), min: 0.8 },
    edge_type: "SIMILAR".into(),
    namespace: Some("tenant-a".into()),
    ..rule_defaults()
})?;
}

• Scoping is not a filter applied after derivation. A scoped rule’s candidate index holds only its own namespace, and each side of every pair it considers is checked, so no cross-namespace edge is ever written and then removed. There is no pair-level check to get wrong.
• A global rule is unchanged code: with namespace: None the engine takes no namespace read at all, so every rule written before namespaces existed behaves byte-identically and costs exactly what it did.
• A via-hop rule is scoped the same way. The via node is a node, so a scoped rule never hops through another namespace to reach a destination.
• A rule is the only way to get a cross-namespace edge, and only a global one: a user-written edge across a boundary is refused (masks.md).
• A name that is not a valid namespace (1–64 of [A-Za-z0-9_.-]) is refused when the rule is created.
• A rule persisted before this field existed decodes as namespace: None — global, which is the behaviour it had.

namespace is accepted wherever a RuleDef is: POST /rules, the MCP create_rule tool, Python’s create_rule({... "namespace": "tenant-a"}), and a mushroomdb schema apply schema file. Omitting it is a global rule on all four.

Namespaces themselves — the reserved ns property, how a role binds to one, and the cross-namespace edge refusal — are documented in masks.md.

Provenance and explain

Every derived edge records which rule produced it. Query it via:

GET /explain?a=person-01&b=proj-01

Response:

[
  {"rule": "auto_fk_person_project_id", "edge_type": "PROJECT",
   "src": "person-01", "dst": "proj-01", "weight": 1.0},
  {"rule": "skill_fit", "edge_type": "FIT",
   "src": "person-01", "dst": "proj-01", "weight": 1.0}
]

The UI why panel renders this as human-readable arithmetic for each predicate kind.

Each entry also carries via_edge: the edge type a via-hop rule hops over, or null for a plain two-node rule.

Chaining

A via-hop rule reads edges. Those edges can themselves be rule-derived, so one write cascades: setting File.top_author_id refires the FK rule that owns TOP_AUTHOR, and the new TOP_AUTHOR edge immediately refires every via-hop rule that hops over TOP_AUTHOR — KNOWS, say. All of it lands in the same commit. Retraction chains the same way: an edge that disappears takes the edges derived from it with it — including when the edge disappears because you deleted the rule that owned it, or removed one of its endpoints.

The rules of the cascade:

• Depth 4. A write chains at most four levels past the rule that fired first. A longer chain stops there, leaving the levels beyond it at their previous values, and no later write repairs them — a write that touches the root chains four levels again and never reaches the fifth. The cap is MAX_CHAIN_DEPTH, exported from the crate root. When a write hits it with work still pending, stats().chain_truncations goes up; a non-zero value there means some derived edges are stale and the rule chain needs shortening or splitting. The counter is not persisted, so it starts at zero on every open and is re-accumulated by replay.
• Once per rule and source, per level. Within one chain level each (rule, source node) pair is recomputed at most once. Every edge a level consumes was already written before that level began, and a recompute is a full re-evaluation of the source’s desired edge set rather than a patch, so a second pass at the same level could only repeat itself. Across levels the guard is released: a rule that ran at one level still refires at the next if another rule wrote an edge it hops over. Each such chained recompute of a via-hop rule increments that rule’s stats().rules[].fires counter the same as a top-level fire, so a rule that sits deep in a chain reports more fires than the number of writes that triggered it.
• Deterministic. Derived edges are consumed in the order they were written and rules are visited in name order, so a chain produces the same result every time. WAL replay runs the identical hooks, so a reopened store reproduces the identical chained edges — and the identical truncations.
• Nothing derives onto a node being deleted. A delete retracts that node’s derived edges and chains those retractions, but the node is excluded from every role a rule could put it in while the delete is in flight, so the chain cannot hand it a new edge on the way out.
• No cycles. See below.

Cycles are rejected at rule creation

A rule set where A hops over an edge B writes, and B hops over an edge A writes, would refire itself forever; the depth cap would silently cut it short at an arbitrary point. So create_rule rejects it outright:

RuleInvalid: rule chain cycle: KNOWS -> TOP_AUTHOR -> KNOWS

The path names the edge types around the loop. A rule whose via_edge equals its own edge_type is rejected the same way. Rules created earlier in the same batch count too, so a batch cannot assemble a cycle one rule at a time and have both halves accepted.

Views are not part of this. A rule cannot read a view, so a view computed from derived edges never feeds another rule and cannot close a cycle. View-fed rules remain designed, not shipped.

Backfill and max_edges

When a rule is declared on a graph that already has nodes, mushroomdb backfills — it evaluates the predicate against all existing node pairs. For rules without a max_edges cap this is O(|src_nodes| × |dst_nodes|) pair evaluations.

Top-k per-source semantics (max_edges: Some(k))

Setting max_edges: Some(k) gives the rule per-source top-k semantics: each source node derives at most k outgoing edges, keeping only the best-scoring destinations:

• Scored predicates (NumericWithin, VectorSimilar): destinations ranked by score DESC, then destination key ASC as a tiebreak.
• Unscored predicates (KeyMatch, FieldEqual): destinations ranked by destination key ASC.

When a new candidate beats the current k-th score it is inserted and the weakest existing edge is evicted. When a destination node is removed, affected sources automatically backfill from the next-best candidate.

Always set max_edges on high-fanout rules at large scale. A FieldEqual rule on 70k Talent × 20k Company nodes with max_edges: Some(5) produces at most 5 edges per source — evaluation stays linear in |src_nodes|.

After a rule is declared, incremental firing on each new write is cheap (sub-millisecond for most predicates) because only the changed node’s field wakes the rule.

Ceiling note: max_edges: Some(k) is the only ceiling for per-source rules — there is no additional defensive cap. A rule with k = 1_000_000 on a graph with 100k source nodes can create up to 10¹¹ edges during backfill. Choose k relative to the expected candidate-set size per source.

Global-budget semantics (max_edges: None)

When max_edges is None, the rule uses a global runaway guard: materialization stops after DEFAULT_MAX_EDGES (1 000 000) total edges and the rule is marked tripped. No further edges are added until the rule is rebuilt with nodes removed. Use max_edges: Some(k) instead when you want per-source cardinality control.

Known limitations

• Two-hop Cypher joins over dense derived-edge sets hit a 1M-row intermediate-result cap before LIMIT is applied. Use the traversal API (node_edges / neighborhood) for multi-hop lookups on large graphs. LIMIT pushdown is on the roadmap.
• WAL-only cold-start re-fires all rules from node data. At 100k nodes (9 rules), re-open takes ~8.16 min; ANN index (HNSW) re-fitting dominates. A snapshot persists the derived edges and the ANN state, so opening from one takes 0.02 s at 100k (measured on V8). Call snapshot() before close to avoid re-derivation on next open.
